Takeuchi TB014 User Manual

47
CONTROLS
Starter Switch
IMPORTANT: Do not repeatedly switch
the key from OFF to ON and ON to OFF
over a short period. Doing so will cause
engine breakdown.
PREHEAT..... Position for preheating the
engine.
OFF .............. Position for stopping the
engine and inserting or
removing the key.
ON ................ Position in which the engine
is running. At this position, all
the electrical equipment is
functional.
START .......... Position for starting the
engine. When the key is
released, the switch
automatically returns to the
ON position.
Switches
PREHEAT
START
ON
OFF
E4B010
Horn Switch
Press the switch on the right operating lever
to blow the horn.
Travel Speed Switch
Press this switch to set the travel speed to
2nd speed (high speed). Press again to
return to 1st speed (low speed).

Takeuchi TB014 Specifications

General

Engine	Yanmar 3TNV70
Overall Width	980 mm
Transport Width	980 mm
Bucket Capacity	0.04 m3
Max Digging Depth	2260 mm
