OPTIONS
Hydraulic Breaker
For handling of the breaker, read the
hydraulic breaker’s manual, provided
separately.
< TB016 >
Do not use a breaker with the crawler
width narrowed!
WARNING
¡¡
¡¡
¡ When operating the machine, always
set the crawler width to 1300 mm (51
in.) for a more stable posture.
Operating with the crawler width
narrowed (980 mm (39 in.)) makes the
machine unstable and may cause it to
tip over.
¡¡
¡¡
¡ If you must operate with the crawler
width narrowed (980 mm), fold in the
hoe attachment, and lower the boom
to lower the center of gravity, and set
the machine facing directly forward
before traveling.
When operating such optional attachments
as a breaker, tilted bucket or clamshell,
always set the crawler width to 1300 mm (51
in.) before operating.
IMPORTANT: When mounting devices,
select devices suited for this machine.
For advice on selecting device, contact a
Takeuchi sales or service outlet.
Precautions on Operating
¡ Run the engine with 75% the maximum
speed.
¡ Pound with the chisel perpendicular to the
surface you are pounding.
¡ When pounding, press the chisel properly
against the object to be broken so as to
avoid pounding the air.
¡ Do not pry with the chisel, and do not pry
while pounding.
¡ Do not move the chisel while pounding.
¡ Do not pound continuously for over 30
seconds on the same surface.
Pressing force
D5L005

Takeuchi TB014 Specifications

General

Engine	Yanmar 3TNV70
Overall Width	980 mm
Transport Width	980 mm
Bucket Capacity	0.04 m3
Max Digging Depth	2260 mm
