Takeuchi TB014 User Manual

53
CONTROLS
Heater (Cab)
WARNING
¡¡
¡¡
¡Always be sure to allow sufficient
ventilation.
¡¡
¡¡
¡Do not place combustible or explosive
objects near the air outlets.
Heater Fan Switch
O ...... Off
I ....... Heater fan rotates at low speed.
II ....... Heater fan rotates at high speed.
Heater / Defroster Switch
Use this switch to heat the cab and to defrost
the windshield.
(A) .... Heater
(B) .... Windshield defroster
Ventilation / Circulation Switch
(C) .... Full ventilation
(D) .... Internal circulation
Supplement: Use the heater with care in
warm seasons. Coolant circulates in the
heater even when the heater switch is
turned off.
When the heater is no longer needed, stop
coolant circulation as follows:
IMPORTANT: Use the valve (1) either fully
open or fully closed.
Cooling water could leak when the valve
is set at a halfway position.
1. Park on a flat surface and stop the engine.
2. Open the engine hood.
3. Turn the valve (1) clockwise until it stop to
close it.
Accessories
O
I
II
C4C014
C4C015
A
B
C4C029
D
C
〈
TB016
〉〈
TB014
〉
1
1

Takeuchi TB014 Specifications

General

Engine	Yanmar 3TNV70
Overall Width	980 mm
Transport Width	980 mm
Bucket Capacity	0.04 m3
Max Digging Depth	2260 mm
