165
SPECIFICATIONS
Lifting Capacities
Rated lift capacity chart
¡ The loads in the charts do not exceed 87% of hydraulic lift capacity or 75% of tipping load.
¡ Rated lift capacities limited by rated hydraulic lift capacity are identified by an asterisk(*)
¡ The mass of slings and any auxiliary lifting devices shall be deducted from the rated load
to determine the net load that may be lifted.
¡ The load point is the bucket hinge pin, and the bucket posture is with the standard bucket
completely retracted under the arm.
¡ Units: kg (lbs.)
Load hooking system
A load hooking system with all of the following capacities must be provided and used.
1. A system which can withstand a weight of two times the rated lift capacity no matter at
what position the load is applied.
2. A system in which there is no risk of the lifted load falling from the hooking device, for
example one equipped with a hook slippage prevention device.
3. A system in which there is no risk of the hooking system slipping from the hoe attachment.
WARNING
¡¡
¡¡
¡ DO NOT attempt to lift or hold any load that is greater than these rated values at
their specified load radii and height.
¡¡
¡¡
¡ All rated lift capacities are based on the machine being level and on a firm supporting
surface. For safe working loads, the user is expected to make due allowance for the
particular job conditions such as soft or uneven ground, non-level condition, side
loads, hazardous conditions, experience of personnel, etc. The operator and other
personnel should fully acquaint themselves with the operator’s manual furnished
by the manufacturer before operating this machine, and rules for safe operation of
equipment shall be adhered to at all times.
