Takeuchi TB014 User Manual

185
OPTIONS
ISO
A
JCB
G
C4L004
The operating pattern of the left and right operating levers can be changed.
WARNING
Before starting the engine, check the selector to see which operating pattern the left
and right operating levers are set for.
Switching the Lever Pattern
(A) : ISO pattern
(G): JCB pattern
1. Open the maintenance cover.
2. Loosen the wing bolt (2) from selector
valve (1).
3. Turn the lever (3) to switch the pattern.
Switching the Lever Pattern
ISO
JCB
4. Tighten the wing bolt (2) and fasten the
lever (3) in place.
5. Close the maintenance cover and check
the lever pattern.
C4L003
A
G
3
2
1

Takeuchi TB014 Specifications

General

Engine	Yanmar 3TNV70
Overall Width	980 mm
Transport Width	980 mm
Bucket Capacity	0.04 m3
Max Digging Depth	2260 mm
