Takeuchi TB014 User Manual

81
OPERATION
Operating Procedures
Traveling Posture
Traveling up slopes
When traveling up slopes at an angle of 15°
or greater, travel in the posture shown in the
diagram above.
Traveling down slopes
When traveling down slopes at an angle of
15° or greater, lower the engine speed and
travel in the posture shown in the diagram
above.
Braking when traveling down slopes
When traveling down slopes, the brakes are
applied automatically when the travel levers
are returned to the neutral position.
If the crawlers slip
If the crawlers slip while traveling up a slope,
use the pulling force of the arm to climb the
slope.
If the engine stops
If the engine stops when traveling down a
slope, set the travel levers to the neutral
position, stop the machine, then start the
engine.
Climbing
E4D046
E4D045E
Braking
Descending
E4D047E

Takeuchi TB014 Specifications

General

Engine	Yanmar 3TNV70
Overall Width	980 mm
Transport Width	980 mm
Bucket Capacity	0.04 m3
Max Digging Depth	2260 mm
