Function
2
DISPLAY DESCRIPTION
Descri
Icon
ption
R
T
SC
MAIN
Modulati
A Segment
B Segment
Transmit
Signal
Strength
Received
Signal
Strength
on Level
Receive and transmit frequencies are inverted in frequency mode/channel mode.
Off-network mode, the transmit and receive frequencies are adjusted to the same.
Special voice encryption status/frequency hopping function.
Main frequency or channel.
Indicates the respective frequency segment.
Current strength of the transmitted signal.
Current strength of the received signal.
Current amplitude of the transmitted audio.
Battery
Displays the remaining battery power. When the battery is about to run out, the
outer frame of the symbol flashes, and the transceiver prohibits transmission.
Icon
BATTERY STATUS
The battery has sufficient capacity.
The battery is exhausted a little.
The battery is nearing exhaustion.
The battery is almost fully exhausted. Immediately charge thebattery pack.
*After a while, the icon blinks and the transceiver will beturned OFF.
