ix)
Change
the
connection
of
the
oscilloscope
as
in
item
(b).
x)
Key
in
"CS".
(TOO TIMING SEEK
±S)
xi)
Loosen
the
fixing
screw
of
the
track
00
sensor
(see
Fig.428)
and
adjust
the
sensor
position
so
that
the
timing
tA
in
Fig.427
falls
within
the
following
range.
Adjusting
target
of
tA:
3.4
~
4.6msec
xii)
Repeat
the
adjustment
so
that
the
values
in
item
xi)
fall
within
the
specified
range
when
the
fixing
screw
has
been
tightened
with
the
specified
torque.
xiii)
Apply
a
drop
of
locking
paint
to
the
fixing
screw
head.
xiv)
Adjust
the
track
00
stopper
according
to
item
4-4-12.
-
