49
+ Available Separately
Models PH71/PH84 Parts List
DESCRIPTION PARTS
UPDATE
REMARKSWARR.
CLASS
PH84
QTY.
PH71
QTY.
PART
NUMBER
O--RING--7/8 OD X .103W 014402 3 000
KIT A.--3 SPT. DOOR FLD. REPLACEMENT X51532--1 1 103 MUST USE ON UNITS BEFORE S/N J5080000
TO REPL. X41954--SER DOOR A.
96
BEARING--FRONT 050348 2 000 W/FRONT SHOES (X50350--KIT) DOOR A.--3 SPOUT X51532--11 1 103 GASKET--DOOR HT 4” --DOUBLE 048926 2 000 NUT-- STUD FLAT END--2--9/16 LONG 034383 2 103 REPLACES 048929 NUT--STUD FLAT END--3--1/4 LONG 034382 2 103 REPLACES 048928 O--RING--7/8 OD X .103W 014402 7 000 SEAL--DRAW VALVE 034698 1 000
KIT A.--TUNE UP--1 SPOUT-- HT X49463--8 1 000 REPLACES X45638 98 & 107
BEARING--FRONT 023262 1 000 CAP--DESIGN--1.010”ID--6 POINT 014218 1 000 GASKET--DOOR HT 4” --DOUBLE 048926 1 000 O--RING--1--3/4 OD X .139W 008904 1 000 O--RING--1--3/4 OD X .139W 015835 1 000 MIX INLET TUBE O--RING--1--3/4 OD X .139W 016272 1 000 PIVOT PIN O--RING--1--3/4 OD X .139W 014402 3 000 DRAW VALVE O--RING--1--3/4 OD X .139W 022473 1 000 O--RING--1--3/8 OD X .103W 018664 1 000 LIQUID VALVE BODY O--RING--11/16ODX.103W--RED 016132 2 000 FEED TUBE O--RING--2--1/8 OD X .139W 020051 4 000 LIQUID VALVE BODY/PISTON RING-- CHECK 1--1/4 OD X 3/8 033215 1 000 LIQUID VALVE BODY RING-- CHECK 2 IN O D X 1/2 020050 2 000 LIQUID VALVE BODY SEAL--AIR INLET FITTING 045327 1 000 SEAL--CUP-- 3/4OD X 1/2ID X 1/8TK 048632 2 000 PUMP DRIVE SHAFT SEAL--DRIVE SHAFT 032560 1 000 TOOL-- 0--RING REMOVAL 048260--WHT 1 000
KIT A.--TUNE UP--3 SPOUT-- HT X49463--1 1 000 REPLACES X42790 98 & 107
BEARING--FRONT 050348 2 000 W/FRONT SHOES (X50350--KIT) CAP--DESIGN--1.010”ID--6 POINT 014218 3 000 GASKET--DOOR HT 4” --DOUBLE 048926 2 000 O--RING 1/2 ID X .139W--206 048632 4 000 PUMP DRIVE SHAFT O--RING--1--3/4 OD X .139W 008904 2 000 MIX PUMP/DRIVE SHAFT O--RING--1--3/8 OD X .103W 018664 2 000 LIQUID VALVE BODY O--RING--11/16ODX.103W--RED 016132 4 000 FEED TUBE
