+ Available Separately
50
Parts List Models PH71/PH84
DESCRIPTION PARTS
UPDATE
REMARKSWARR.
CLASS
PH84
QTY.
PH71
QTY.
PART
NUMBER
O--RING--2--1/8 OD X .139W 020051 8 000 LIQUID VALVE BODY/PISTON
O--RING--3/4 OD X .103W 015835 2 000 MIX INLET TUBE
O--RING--5/16 OD X .070W 016272 1 000 PIVOT PIN
O--RING--7/8 OD X .103W 014402 7 000 DRAW VALVE
POPPET--RUBBER--BLACK 022473 2 000
RING-- CHECK 1--1/4 OD X 3/8 033215 2 000 LIQUID VALVE BODY
RING-- CHECK 2 IN O D X 1/2 020050 4 000 LIQUID VALVE BODY
SEAL--AIR INLET FITTING 045327 2 000
SEAL--DRAW VALVE 034698 1 000 CENTER DRAW VALVE
SEAL--DRIVE SHAFT 032560 2 000
TOOL-- 0--RING REMOVAL 048260--WHT 1 000
LABEL--CAUTION--AGITATOR 045191 1 2 000 MIX HOPPER
LABEL--MOVING PARTS WARNING 024315 3 3 000
LABEL-- WARN--COVER 051433 5 8 000
LOUVER--SIDE 017471 2 1 103 Left side on H84
LOUVER--SIDE 028288 1 103 Right side on H84
LUBRICANT--SUPER TAYLOR 4 OZ.TUBE 048232 1 1 000
MAN--OPER H71/H84 048886--M 1 1 000 J5032440/UP 91
MOTOR--1.5 HP 021522-- 1 2 212
CAPACITOR--START 045862 1 2 103 LEESON--230--60--1
CAPACITOR--RUN 036084 1 2 103 LEESON--230--60--1
CAPACITOR--START 028315 1 2 103 CENTURY--230--60-- 1
CAPACITOR--RUN 033050 1 2 103 CENTURY--230--60-- 1
MOTOR--AGITA TOR 047987-- 1 1 103 BEGIN APPROX 3--1--94 84
MOTOR--AGITA TOR 039468-- 1 1 103 OLD STYLE 84
MOTOR-- REDUCER 32 RPM-- HPR PUMPM 036955--34 1 2 103
CAPACITOR 037251-- 1 2 103
COUPLING--MOTOR -- FLEXIBLE 047936 1 2 103 86
GEAR--ONLY 049247--34 1 2 103 93
MOTOR--ONLY 049246--34 1 2 103 93
NUT--OVERLOAD--RESET 045026 1 2 000
OVERLOAD--TI #2BMKK20--71 044464 1 2 103 KLIXON
RELAY--MTR START TI#4CR--1--625 039725-- 1 2 103 PUMP MOTOR
SEAL--MOTOR R EDUCER--INPUT SHAFT 048836 1 2 000 90
SEAL--MOTOR REDUCER--OUTPUT SHAFT 048837 1 2 000 90
NUT-- STUD 021508 4 103 J5080000/UP 96
