Taylor PH90 - Beater Door Assembly - Soft Serve Side

11
Model PH90 Operator Parts Identification
130724
Beater Door Assembly - Soft Serve Side
Figure 3
ITEM DESCRIPTION PART NO.
1 SEAL- DRIVE SHAFT 032560
2 SHAFT- BEATER 032564
3 BEATER A.- 3.4QT- 1 PIN X46231
4 CLIP - SCRAPER BLADE 7” 046236
5 BLADE- SCRAPER- PLASTIC 046235
6 KIT A.- BEATER- FRONT
SHOES- BEARING
X50350
7 GASKET- DOOR HT 4” 048926
8 FREEZER DOOR A. X51531- 9
9 HANDLE A.- DRAW
ADJUSTABLE - COMPLETE
X55095
ITEM DESCRIPTION PART NO.
9a HANDLE- DRAW VALVE 044197
9b SCREW - ADJUSTMENT 055092
9c O- RING- 1/4 OD X .070W 50 015872
9d NUT- 5/16 - 24 FINISHED HEX 029639 - BLK
10 O - RING - 5/16 OD X .070W 016272
11 PIN A.- PIVOT X22820
12 NUT- STUD 021508
13 VALVE A.- DRAW X33582
14 O - RING - 7/8 OD X .103W 014402
15 CAP- DESIGN 1.010”ID 014218
