Model PH90 Important: To the Operator
Section 5 Important: To the Operator
Figure 9
ITEM
DESCRIPTION
1 Power Switch (Toggle)
2 Indicator Lights (PCB A.- LED)
3 Flavor Selector Keypad
(Switch- Membrane)
4 Liquid Crystal Display
5 Keypads (Switch- Membrane)
6 Heater Switches (Toggle)
Symbol Definitions
To better communicate in the International arena, the
words on many of our operator switches and buttons
have symbols to indicate their functions. Your Taylor
equipment is designed with these International
symbols.
The following chart identifies the symbol definitions.
=OFF
=ON
=CALIBRATE
= WASH
=PUMP
=AUTO
=MENU
=MIXLOW
= MIX OUT
=HEATMODE
= CLEAN MANUALLY/BRUSH CLEAN
= CHOCOLATE
= STRAWBERRY
= VANILLA
= OPTIONAL
