TCGRx ATP-E320W - Page 16

ATP Operator Instructions
|Installation
16
2. Secure the unit to the floor using anchor bolts (Figure 3-2)
a. Place the bolts in the four floor brackets to secure the unit to the floor.
b. Use the nuts to tighten the anchor bolts.
Figure 3-2
Note: Remove the cable tie from the power cord. The covering of the power cord could corrode if the cord stays
bundled up for too long
