ATP Operator Instructions
How to Replace the Cutter Blade
The blade should normally be replaced every 2 or3 months. The cutter blade should be replaced when a
cutter alarm occurs or when the packaging paper is not cut properly.
[Step 1]
Loosen screw A and slide the part to
retract the blade.
[Step 2]
Lift Part B and remove the cover.
[Step 3]
Remove the screw in Part A and remove
the cutter blade.
[Step 4]
Install the new cutter blade by following
the above steps in reverse order. Slide
the screw all the way forward to extend
the blade, and then retighten the screw.
