ATP Operator Instructions
|Part Names and Functions
TC Drawer
A TC drawer is a drawer for storing TK-60S tablet canisters.
Each drawer holds 8 canisters on the left and 8 canisters on the right side for a total of 16 tablet canisters.
(1) Open switch
A lock release switch that allows you to open a TC drawer.
Press this switch to release the lock before pulling out a drawer.
(2) LED lamp
An LED on the front panel lights when there are no medications in the tablet canister or when a
malfunction is detected.
There is one LED on the right and left sides of the unit that indicate on which side the malfunction
occurred.
Pull out only one TC drawer in a row during filling or other operation.
The cabinet could turn over and injure somebody if several storage drawers are pulled out at the same
time.
