TDE MACNO DVS200 - Page 56

56  Chapter 7 - Parameters Description User Manual
IPA
CODE NAME
PARAMETER PICK LIST
DESCRIPTION
[CODE]
FUNCTION
DESCRIPTION
DEFAULT
MIN
MAX
UNIT
VARIATION
HIDDEN
H.000
H.010
H.040
H.050
H.051
H.052
H.053
H.054
H.055
H.056
H.057
H.064
H.500
H.501
H.502
H.503
H.504
H.505
H.506
H.507
H.508
H.509
H.510
Virtual digital command
Virtual digital state
Progress
Drive output frequency 16 bit low (d.000)
Drive output frequency 16 bit high (d.000)
Drive reference frequency 16 low (d.001)
Drive reference frequency 16 high (d.001)
Output speed (d.000)*(P.600)16 bit low (d.007)
Output speed (d.000)*(P600)16 bit high(d.007)
Speed Ref (d.001)*(P.600) 16 bit low (d.008)
Speed Ref (d.001)*(P.600)16 bit high(d.008)
Estimated real speed
Harware reset
Alarm reset
Coast to stop
Stop with ramp
Clockwise Start
Anti-clockwise Start
Clockwise Jog
Anti-clockwise Jog
Clockwise Flying restart
Anti-clockwise Flying restart
DC Brake
0
0
0
0
0
0
0
0
0
0
0
0
0
0
0
0
0
0
0
0
0
0
0
0
0
- 2
31
- 2
31
- 2
31
- 2
31
- 2
31
- 2
31
- 2
31
- 2
31
0
0
0
0
0
0
0
0
0
0
0
255
255
100
2
31
-1
65535
65535
65535
65535
32767
32767
32767
1
1
1
1
1
1
1
1
1
1
1
1000
1002
1009
1010
1011
1012
1013
1014
1015
1016
1017
1046
1029
1030
1031
1032
1033
1034
1035
1036
1037
1038
1039
Virtual I/Os CommandsProfidrive Profile
Drive Status
Parameters Reading Extension
This menu is not available on the
keypad. The setting and the reading of
the parameters here contained, can
be performed exclusively via serial line
or through SBI card.
