TDE MACNO DVS200 - Menu d - DISPLAY

User Manual Chapter 7 - Parameters Description  57
7.2 Menu d - DISPLAY
Basic
d.000 Output frequency
Drive output frequency [Hz].
d.001 Frequency ref (Frequency reference)
Drive frequency reference [Hz] .
d.002 Output current
Drive output current (rms) [A].
d.003 Output voltage
Drive output voltage (rms) [V].
d.004 DC link voltage
DC Bus drive voltage (DC) [V].
d.005 Power factor
Power factor.
d.006 Power [kW]
Active power.
d.007 Output speed
Drive output speed (d.000)*(P.600).
d.008 Speed ref (Speed reference)
Drive speed reference (d.001)*(P.600).
Code Name [Code] & Function Default MIN MAX Unit Variation IPA
d.000 Output frequency Hz 0,01 001
d.001 Frequency ref Hz 0,01 002
d.002 Output current A 0,1 003
d.003 Output voltage V 1 004
d.004 DC link voltage V 1 005
d.005 Power factor 0,01 006
d.006 Power [kW] kW 0,01 007
d.007 Output speed 0.01 / 1 008
d.008 Speed ref 0.01 / 1 009
Overload
d.050 Heatsink temp (Heatsink temperature)
Drive heatsink temperature [°C] (linear sensor measured).
d.051 Drive OL (Drive overload)
Drive overload (100% = alarm threshold).
