TDE MACNO DVS200 - Page 59

User Manual Chapter 7 - Parameters Description  59
d.151 Term dig out sta (Terminal digital outputs status)
Status of the digital outputs terminal of the drive regulation board.
See example d.150
d.152 Vir dig out stat (Virtual digital outputs status)
Status of the virtual digital outputs executed by the drive serial link or field bus card.
See example d.150
d.200 An in 1 cnf mon (Analog input 1 configuration monitor)
It monitors the analog input 1 signal destination; it is possible to know which function is associated to this input:
[0] Null funct None function programmed
[1] Freq ref 1 Frequency reference 1 chapter FREQ & RAMPS, section Reference sources (F.050)
[2] Freq ref 2 Frequency reference 2 chapter FREQ & RAMPS, section Reference sources (F.051)
[3] Boost lev fac Level of voltage boost chapter PARAMETERS, section Boost (P.121)
[4] OT level fact Level of over torque chapter PARAMETERS, section OT level factor src (P.242)
[5] V red lev fac Output voltage reduction level chapter PARAMETERS, section Voltage Red Config P.422)
[6] DCB level fac DC braking current level chapter PARAMETERS, section DC brake Config (P.301)
[7] Ramp ext fact Ramp extension factor chapter PARAMETERS, section Ramp Config (F.260)
d.201 An in 1 monitor (Analog input 1 monitor)
Analog input 1 - output block (% value).
d.202 An in 1 term mon (Analog input 1 terminals monitor)
Analog input 1 input block % value (regulation board).
It monitors the input signal depending on the selection of An inp 1 Type (I.200) parameter:
 selection: [1] 0-10V/0-20mA: 0V = 0%, +10V = +100% o 0mA=0% 20mA =
+100%
 selection: [2] 4-20mA: 4mA = 0%, 20mA = +100%
Code Name [Code] & Function. Default MIN MAX Unit Variation IPA
d.100 Dig inp status 014
d.101 Term inp status 015
d.102 Vir dig inp stat 016
d.150 Dig out status 020
d.151 Term dig out sta 021
d.152 Vir dig out stat 022
d.200 An in 1 cnf mon 026
d.201 An in 1 monitor % 027
d.202 An in 1 term mon % 028
Pid
d.400 PID reference
PID reference signal.
d.401 PID feedback
PID feedback signal.
d.402 PID error
PID error signal.
