68 Chapter 7 - Parameters Description User Manual
7.4 Menu I - INTERFACE
Digital Inputs Regulation Board
I.000 Dig input 1 cfg (Digital input 1 configuration)
I.001 Dig input 2 cfg (Digital input 2 configuration)
I.002 Dig input 3 cfg (Digital input 3 configuration)
I.003 Dig input 4 cfg (Digital input 4 configuration)
I.004 Dig input 5 cfg (Digital input 5 configuration) Not used
The regulation board provides as standard 8 opto-coupled digital inputs. A PNP or NPN logic level, can be selected according
to figure 5.5.1. Every input is programmable with a specific code and function, as shown in the list below.
DIGITAL INPUTS SELECTION LIST:
Code LCD display Description
0 None Not active
1Run RUN command for the motor START
2 Reverse Speed REVERSE command
3 Ext Fault NO External fault with NO (Normal Open) contact
4 Ext Fault NC External fault with NC (Norm. Closed) contact
5 Alarm reset Alarm reset command
6Jog JOG frequency reference enabling
7 Freq sel 1 Binary selection for Multispeed
8 Freq sel 2 Binary selection for Multispeed
9 Freq sel 3 Binary selection for Multispeed
10 Freq sel 4 Binary selection for Multispeed
11 Ramp sel 1 Binary selection for Multiramp
12 Ramp sel 2 Binary selection for Multiramp
13 Enable NO Drive Enable with NC (Norm. Closed) contact
14 Enable NC Drive Enable with NO (Normal Open) contact
15 DCBrake en Enabling of the DC braking function
16 DCBrake Command for execution of DC braking
17 Autocapture Execution of the flying restart
18 Ramp enable Enabling / Disabling of the Ramp block
19 Zero ref Ramp to 0Hz & main commands active
20 PID enable Enabling of the PID regulation
21 PID freeze Enabling PID freeze output signal.
22 PID gain sel Initilizing of the Integral value of PID
23 Motorpot Up Motorpotentiometer reference increasing
24 Motorpot Dn Motorpotentiometer reference decreasing
25 Reset Motorp Reset of Motorpotentiometer reference
26 Fast stop Emergency stop (with Dec time 3 delay)
27 Zero freq Enabling output freq. to zero.
Code Name [Code] & Function Default MIN MAX Unit Variation IPA
I.000 Dig input 1 cfg See Digital inputs selection list 7 0 27 100
I.001 Dig input 2 cfg As for I.000 8 0 27 101
I.002 Dig input 3 cfg As for I.000 9 0 27 102
I.003 Dig input 4 cfg As for I.000 6 0 27 103
