TDE MACNO DVS200 - Page 67

User Manual Chapter 7 - Parameters Description  67
Code Name [Code] & Function Default MIN MAX Unit Variation IPA
S.400 Manual boost [%] 1 0 25 % of S.100 421
S.401 Auto boost en [0] Disable 0 0 1 423
[1] Enable
S.450 Slip compensat 0.1 0 10 % 419
S.451 Slip comp filter 0.1 0 10 sec 0.1 420
Utility
S.900 Measure stator R (Measurement of stator resistance)
It measures the stator resistance of the motor connected.
This will help to provide a smooth and uniform value of the output torque through the whole speed range.
The control is assisted by the use of the Automatic boost (P.401).
Do not perform any tune when a multiple motor connection is being used.
S.901 Save parameters
Every changing of each parameter, is accepted and executed by the drive.
However, the permanent storage of them, is performed only by the execution of this command.
The lack of this operation will cause the loss of every changed parameter when the power is disconnected from
the drive.
Code Name [Code] & Function Default MIN MAX Unit Variation IPA
S.900 Measure stator R Confirm ? off off off do 806
Confirm ? do
S.901 Save parameters Confirm ? off off off do 800
Confirm ? do
Here below is an example of how to execute the Save parameters command. It is also valid for Measure
stator R (S.900) command.
STARTUP S901
Save parameters
E
Save parameters
Confirm? NO
E
Save parameters
Run
Save parameters
Done
STARTUP S901
Save parameters
Save parameters
Confirm? YES
