– 34 –
EO1-11097
STORE NAME/MESSAGE AND COMMERCIAL MESSAGE
PROGRAMMING (Submode 1)
Any time outside a sale
Mode Lock: SET
NOTES: 1. For each line, a maximum of 24 regular-size characters or 12 double-sized characters
may be entered. A combination of both types is also available.
2. Even if the option “Store Name Print by RUBBER STAMP” is selected, data can be
programmed for the store name/message. However, the Rubber Stamp, instead of the
programmed name/message will actually be printed for operations to issue receipts.
If the option “Store Name Print by DOT PRINTER” is selected, use 1 through 4 for the store
name/message and 5 through 7 for the commercial message data, as Line No.
The range Line Nos. 5 to 7 is unavailable to a manual-cut printer.
3. If no commercial message is required on the receipt, program blanks for all three lines.
As a result no extra lines will be fed. If any one of the three lines is programmed, the two
other lines will cause line feeds.
4. The 4-line range assigned for the store name/message will be either printed or fed,
regardless of any system option selection.
5. If any incorrect characters have been programmed, depress the [C] key to clear all the
characters on a line and then re-enter characters from the beginning, or end the line with
an [ST] and re-program the entire line. The new data will be active.
6. When all the lines have been programmed, do a check by issuing receipt. Only the lines
with errors need to be re-programmed; other lines will not be affected.
....
To complete this line
Repeat for another line.
| Line No. | [ST]
(For sequentially
programming lines, the line
number specification can be
skipped.)
[AT/TL]
[ST]
1 [X]
Submode No.
Character Entries
max. 24 characters/line
(See CHARACTER ENTRIES
at the beginning of this
chapter.)
....
1 to 4:
or
5 to 7:
....
OPERATION
CONDITION
(See NOTE 2
below.)
....
To complete this
programming
operation
To Next Page
