- 61 -
EO1-11097
3
1
2
4
JF
Replacing the Journal Roll
To remove the Receipt Cover, insert the Receipt Cover Key
to the Receipt Cover Lock, and turn it 90 clockwise.
Depress the [JF] key to wind up enough of the Journal
Paper, then cut the paper as shown in the figure. Depress
the [JF] key to feed the remaining paper end.
CAUTION: Never try to pull out the remaining paper end
by hand.
It may cause paper jamming.
The wound-up portion of the paper can be easily removed
from the Reel by pulling it sideways.
Load new paper roll as described in Chapter 6.
