Technogym spin trainer - The Display Does Not Illuminate

SPIN TRAINER: Service & Maintenance Manual - rev. 2.0
Page 6.2
6.1. THE DISPLAY DOES NOT ILLUMINATE
Are the fuses OK?
Is the mains lead OK?
Is the mains supply correct?
Is the mains voltage present at
the output of the machine’s input
socket?
Replace blown fuses
Replace mains lead
Connect machine to a
suitable
electrical outlet
Replace inlet
socket/on-off switch
block on the
machine
Replace cable SP-3
connecting the inlet
socket/switch block
to the power supply
THE DISPLAY
DOES NOT
ILLUMINATE
Is the mains voltage present at
the power supply input?
NO
YES
NO
YES
NO
YES
NO
YES
YES
1
2
NO
A
Continued on following page.
