SPIN TRAINER: Service & Maintenance Manual - rev. 2.0
Page 7.6
7.6. DISASSEMBLING THE CARDIO RECEIVER
Figure 7.6-1
1. Turn off the machine and unplug the mains
lead from the wall outlet.
2. Remove the CARDIO RECEIVER housing
from its support on the machine.
3. Unscrew the 2 screws a using a small Phillips
screwdriver.
4. Open the housing.
5. Disconnect connector b.
6. Remove the RECEIVER.
To reassemble the RECEIVER, carry out the
above steps in reverse order.
