SPIN TRAINER: Service & Maintenance Manual - rev. 2.0
Page 7.8
7.8. DISASSEMBLING THE GUARD
Figure 7.8-1
1. Turn off the machine and unplug the mains
lead from the wall outlet.
2. Unscrew the 3 self-tapping screws a fixing
the GUARD with a large Phillips screwdriver.
Figure 7.8-2
3. Unscrew the two rear hub supports using a
3-mm hex T-wrench.
4. Remove the 2 rear bicycle hub clamps.
5. Remove the GUARD.
To reassemble the GUARD, carry out the above
steps in reverse order.
