 Technosoft 2019 46 iPOS360x VX-CAN/CAT Technical Reference
3.10.17 Ethernet ports (for CAT drives)
Min.
Typ.
Max.
Units
Standard Compliance
EtherCAT (IEC61158-3/4/5/6-12)
Fast Ethernet 100BASE-TX
(IEEE802.3u)
Auto-negotiation for 100Mbps/s full-
duplex
Auto-detect MDI/MDI-X
Power over Ethernet NOT used by ECAT VX, separate 5V supply compliant to IEEE802.3af mode A
“Mixed DC & Data”
NOT compliant to IEEE802.3af
mode B “DC on Spares”
Isolation GND0,GND1 Requirement for motherboard PCB routing 500 V
rms
1.5 kV
Maximum cable length 2-pair UTP Cat5 100 150 m
ESD protection Human body model ±4 kV
3.10.18 Data communication signals between iPOS drive and ECAT-VX adapter
Min.
Typ.
Max.
Units
Voltage levels 3.3V low-voltage TTL
Noise immunity
0.4
V
Data protocol
4 wire SPI
Data Rate
10
15
MHz
3.10.19 LED signals of ECAT-VX adapter (for CAT drives)
Min.
Typ.
Max.
Units
LED connection
Common anode to 3.3V output
Direct, no series resistor
LED current
8
10
mA
3.3 output voltage
3.15
3.3
3.45
V
3.3 output current
60
mA
3.10.20 Conformity
Min.
Typ.
Max.
Units
EU Declaration
2014/30/EU (EMC),
2014/35/EU (LVD),
2011/65/EU (RoHS),
1907/2006/EC (REACH),
93/68/EEC (CE Marking Directive),
EC 428/2009 (non dual
-
use item, output
frequency limited to 590Hz)
†
Stresses beyond values listed under “absolute maximum ratings” may cause permanent damage to the device. Exposure to absolute-maximum-rated
conditions for extended periods may affect device reliability.
