TD350 Series VFD Function parameter list
-176-
Function
code
Name
Detailed parameter description
Default
value
Modify
P07.50
Ramps reference frequency of the last but one fault
0.00Hz
●
P07.51
Output voltage of the last but one fault
0V
●
P07.52
Output current of the last but one fault
0.0A
●
P07.53
Bus voltage of the last but one fault
0.0V
●
P07.54
Max. temperature of the last but one fault
0.0°C
●
P07.55
Input terminal state of the last but one fault
0
●
P07.56
Output terminal state of the last but one fault
0
●
P08 group Enhanced functions
P08.00
Acceleration
time 2
See P00.11 and P00.12 for detailed definitions.
TD350 series VFD defines four groups of
acceleration/deceleration time, which can be
selected by multi-function digital input terminal (P05
group). The acceleration/deceleration time of the
VFD is the first group by default.
Setting range: 0.0–3600.0s
Depend
on
model
○
P08.01
Deceleration
time 2
Depend
on
model
○
P08.02
Acceleration
time 3
Depend
on
model
○
P08.03
Deceleration
time 3
Depend
on
model
○
P08.04
Acceleration
time 4
Depend
on
model
○
P08.05
Deceleration
time 4
Depend
on
model
○
P08.06
Running
frequency of
jogging
This function code is used to define the reference
frequency of the VFD during jogging.
Setting range: 0.00Hz–P00.03 (Max. output
frequency)
5.00Hz
○
P08.07
Acceleration time
of jogging
Jogging acceleration time is the time needed for the
VFD to accelerate from 0Hz to Max. output
frequency (P00.03).
Jogging deceleration time is the time needed from
decelerating from Max. output frequency (P00.03)
to 0Hz.
Setting range: 0.0–3600.0s
Depend
on
model
○
P08.08
Deceleration time
of jogging
○
P08.09
Jump frequency 1
When the set frequency is within the range of jump
frequency, the VFD will run at the boundary of jump
frequency.
The VFD can avoid mechanical resonance point by
0.00Hz
○
P08.10
Jump frequency
amplitude 1
0.00Hz
○
P08.11
Jump frequency 2
0.00Hz
○
