05-V/F command group
Function
Code No.
Description Range/Code
Factory
Setting
Remarks
05-00
Volts/Hz Curve Modification
(Torque Boost) (%)
0 ~ 30.0 10.0 *5
05-01 Motor No Load Current(Amps AC) ----- *5
05-02 Motor rated Slip Compensation (%) 0.0 ~ 100.0 0.0 *5
05-03 v/f max voltage
220V series : 170.0 ~ 264.0
440V series : 323.0 ~528.0
*5
05-04 Maximum Frequency (Hz) 0. 20 ~ 400.00 50.00/60.00 *5
05-05 Maximum Frequency VoltageRatio (%) 0.0 ~ 100.0 100.0 *5
05-06 Medium Frequency 2(Hz)
0.10 ~ 400.00
25.00/30.00 *5
05-07 Medium Frequency Voltage Ratio2 (%) 0.0 ~ 100.0 50.0 *5
05-08 Medium Frequency1 (Hz) 0. 10 ~ 400.00 10.00/12.00 *5
05-09 Medium Frequency Voltage Ratio1 (%) 0.0 ~ 100.0 20.0 *5
05-10 Minimum Frequency (Hz) 0. 10 ~ 400.00 0.50/0.60 *5
05-11 Minimum Frequency VoltageRatio (%) 0.0 ~ 100.0 1.0 *5
05-12 V/F start Frequency 0.00 ~ 10.00 0.00 *5
06-Motor parameter group
Function
Code No.
Description Range/Code
Factory
Setting
Remarks
06-00 Motor Rated Voltage (VAC) ----- *4
06-01 Motor Rated Current (Amp AC) ----- *4
06-02 Motor Rated Power (kW) ----- *4
06-03 Motor Rated Speed (RPM) ----- *4
06-04 Motor Rated Frequency (Hz) ----- *4
06-05
Reserved Reserved
06-06 Torque Boost Gain (Vector) 0~ 600 *3*4
06-07
Slip Compensation Gain
(Vector)
0 ~ 600 *3*4
06-08
Reserved Reserved
06-09
Reserved Reserved
06-10
Reserved Reserved
06-11
Low-frequency compensation Gain
0 ~ 100 30
