4-11
07-Protection function group
Function
Code No.
Description Range/Code
Factory
Setting
Remarks
07-00 Trip Prevention Selection
xxxx0 :
Enable Trip Prevention During
Acceleration
xxxx1 :
Disable Trip Prevention During
Acceleration
xxx0x :
Enable Trip Prevention During
Deceleration
xxx1x :
Disable Trip Prevention During
Deceleration
xx0xx :
Enable Trip Prevention in Run Mode
xx1xx :
Disable Trip Prevention in
Run Mode
x0xxx : Enable over voltage Prevention in
Run Mode
x1xxx : Disable over voltage Prevention in
Run Mode
00000
07-01
Trip Prevention Level During
Acceleration (%)
50 ~ 200 200
Inverter
Rated
Current
200%
07-02
Trip Prevention Level During
Deceleration (%)
50 ~ 200 200
Inverter
Rated
Current
200%
07-03
Trip Prevention Level In Run
Mode
(%)
50 ~ 200 200
Inverter
Rated
Current
200%
07-04
over voltage Prevention Level in Run
Mode
350.0 VDC ~ 390.0 VDC
700.0 VDC ~ 780.0 VDC
380.0/
760.0
07-05
Electronic Motor Overload Protection
Operation Mode
0 : Enable Electronic Motor
Overload Protection
1 : Disable Electronic Motor
Overload Protection
1
07-06 Motor type Selection
0 : Electronic Motor Overload Protection Set
for Non-Inverter Duty Motor
1 : Electronic Motor Overload Protection Set
for Inverter Duty Motor
0
07-07
Motor Overload Protection
Curve Selection
0 : Constant Torque (OL =103 %)
(150 % for 1 Minute)
1 :
Variable Torque (OL = 113 %)
(123 % for 1 Minute)
0
07-08
Operation After Overload Protection is
Activated
0 : Coast-to-Stop After Overload
Protection is Activated
1 : Drive Will Not Trip when Overload
Protection is Activated (OL1)
0
07-09
Over torque Detection Selection
(OL3)
0 : Disable Over torque Operation
1 : Enable Over torque Operation
Only if at Set Frequency
2 : Enable Over torque Operation
while the Drive is in Run Mode
0
