TeeJet MATRIX 908 - Tractor with Fixed Mount Aft Sprayer

Matrix 908 Field Computer
6
www.teejet.com
CONSOLE START JOB APPENDIXSETUP HELPUTMEASUREMENTS
Tractor with Fixed Mount Aft Sprayer
Vehicle Name:
Table 1-17: Vehicle Wizard Measurements
Description Measurement/Option
Vehicle In-Line Direction to Hitch
Point
Aft of Vehicle Pivot
Point
Vehicle In-Line Distance from the
Vehicle Pivot Point

to Hitch
Point

Vehicle Lateral Direction to Hitch
Point
On Center
Antenna In-Line Direction and
Distance from Vehicle Pivot
Point

to the Antenna

Antenna Lateral Direction
5
and
Distance from vehicle centerline to
the Antenna

Table 1-18: Guidance and Mapping Distances
Description Measurement
Guidance Width
Mapping Location In-Line Distance
from the Vehicle Pivot Point

to the Mapping Location
Mapping Location Lateral Distance
from the Vehicle Centerline
to the Mapping Location
5 When an Assisted/Automatic Steering Device is available, Antenna Lateral
Distance and Direction will be established under the Assisted/Automatic Steering
“Manage Vehicles” settings.
Device Name:
Table 1-19: Device Wizard Measurements
Description Measurement/Option
Hitch Type
Fixed Mount
Boom and Section Layout
Aft Centered
Distance to Boom: In-Line Distance
Hitch/Connection Point

to
Product Delivery Point

Table 1-20: Section Information
Description Option
Section Symmetry
Description Width Measurement
Section 1
Section 2
Section 3
Section 4
Section 5
Section 6
Section 7
Section 8
Section 9
Section 10
Total Application Width
