Matrix 908 Field Computer
34
www.teejet.com
CONSOLE START JOBSETUP HELPMEASUREMENTS UTSTART JOB
Delete Last Guideline
Delete Last Marked Guideline deletes the last
marked guideline from the current job.
1. With the Guidance button on the Feature Bar
active, press the Slide-Out Tray button .
2. Press the DELETE GUIDELINE icon .
3. Press the DELETE GUIDELINE icon again to
remove additional guidelines in order from last to
rst created.
Adjust Guideline
The Adjust Guideline option allows the current
guideline to be shifted to the vehicle’s current
location.
NOTE: Available only when in Straight AB, Azimuth or
Dynamic AB guidance.
Vehicle must be stopped to adjust a guideline.
Assisted/Auto Steering Nudge
The Assisted/Auto Steering Nudge option allows
the vehicle’s current location and guideline to be
temporarily shifted to the left or right by the preset
Nudge distance. Left/right direction is determined
while facing in the machine's forward direction.
Nudge Left
Nudge Right
Assisted/Auto Steering must be active, and Assisted/
Auto Steering Nudge must be enabled. Preset Nudge
distance is established in the Assisted/Auto Steering
settings under General Settings. See "No.8 Set Up
Assisted/Auto Steering" on page 24 for information
on accessing these options.
Each press of an Assisted/Auto Steering Nudge
button adds or subtracts from a previous press.
Total accumulated nudge offset distance can be
displayed on the Guidance Bar. See "Selectable Job
Information" on page 41 for details.
W No change in actual marked guideline will occur.
Switching guidelines, marking a new guideline,
creating a detour, or closing the job will zero out
any accumulated nudge distance.
W Cross-track error will be based on the new
"Nudged" guideline.
