Tektronix AFG31000 Series Service Manual

Removal and installation
68
AFG31000 Series Arbitrary Function Generator Service Manual
Exploded diagram replaceable parts - module rear chassis bottom
Use the following table and figure to determine the replaceable parts and modules in your AFG
module rear chassis-bottom.
Index
number
Tektronix part
number
Instrument model Quantity Name and description
-01
441-2879-00
AFG31021
AFG31051
AFG31101
AFG31151
AFG31251
AFG31022
AFG31052
AFG31102
AFG31152
1
Chassis rear bottom side
441-2918-00
AFG31252
1
Chassis rear bottom side
FIP
-02 878-1399-00 AFG31022
AFG31052
AFG31102
AFG31152
AFG31252
1
Circuit board assembly,
CPU board, 2CH
878-1491-00
AFG31021
AFG31051
AFG31101
AFG31151
AFG31251
1
Circuit board assembly,
CPU board, 1CH
-03
211-1272-00
AFG31021
AFG31051
AFG31101
AFG31151
AFG31251
AFG31022
AFG31052
AFG31102
AFG31152
AFG31252
4
Screw, machine;
6-32 x 0.250, PNH, STL,
ZNPL, T-15 Torx
-04
210-1039-00
AFG31022
AFG31052
AFG31102
AFG31152
AFG31252
5
Washer, lock internal
tooth
210-1039-00
AFG31021
AFG31051
AFG31101
AFG31151
AFG31251
4
Washer, lock internal
tooth
