Tektronix AFG31000 Series Service Manual

Removal and installation
AFG31000 Series Arbitrary Function Generator Service Manual
69
Index
number
Tektronix part
number
Instrument model Quantity Name and description
-05
220-0497-00
AFG31022
AFG31052
AFG31102
AFG31152
AFG31252
5
Nut, plain, hex;
5-28 x .562 hex, BRS, NI
(nickel) plated
220-0497-00
AFG31021
AFG31051
AFG31101
AFG31151
AFG31251
4
Nut, plain, hex;
5-28 x .562 hex, BRS, NI
(nickel) plated
-06
119-7086-00
AFG31021
AFG31051
AFG31101
AFG31151
AFG31251
AFG31022
AFG31052
AFG31102
AFG31152
AFG31252
1
Filter, EMI; ac line
connector/input filter;
6.0A, 120-250 V ac, dc-
400 HZ,2.2 NF CY, 100
NF CX, IEC input, Fast-
on/solder lug output,
chassis mount, safety
controlled; FN9222-6-06
-07
211-0303-00
AFG31021
AFG31051
AFG31101
AFG31151
AFG31251
AFG31022
AFG31052
AFG31102
AFG31152
AFG31252
2
Screw, machine;
4-40 x 0.25, FLH 100
DEG, steel, zinc finish,
T-8 Torx
-08
210-0056-00
AFG31021
AFG31051
AFG31101
AFG31151
AFG31251
AFG31022
AFG31052
AFG31102
AFG31152
AFG31252
2
Washer, lock;
#10 split, 0.047 THK,
SI BRZ NP
-09
213-0610-00
AFG31021
AFG31051
AFG31101
AFG31151
AFG31251
AFG31022
AFG31052
AFG31102
AFG31152
AFG31252
2
Screw machine;
4BA x 1.0, OVH, STL
CRPL, POZ telequipment
