Tektronix AFG31000 Series Service Manual

Removal and installation
70
AFG31000 Series Arbitrary Function Generator Service Manual
Index
number
Tektronix part
number
Instrument model Quantity Name and description
-10
211-0711-00
AFG31021
AFG31051
AFG31101
AFG31151
AFG31251
AFG31022
AFG31052
AFG31102
AFG31152
AFG31252
1
Screw, with washer,
6-32 x .250 panhead,
T-15 Torx
-11
174-7030-00
AFG31021
AFG31051
AFG31101
AFG31151
AFG31251
AFG31022
AFG31052
AFG31102
AFG31152
AFG31252
1
Cable, power auxiliary
power supply to CPU
board
-12
196-3496-00
AFG31021
AFG31051
AFG31101
AFG31151
AFG31251
AFG31022
AFG31052
AFG31102
AFG31152
AFG31252
1
Lead, elect (rear sub-
panel to inlet), safety
controlled
-13
174-5151-00
AFG31021
AFG31051
AFG31101
AFG31151
AFG31251
AFG31022
AFG31052
AFG31102
AFG31152
AFG31252
1
CA assembly, SP, elect;
2, 18 AWG, 7 CML, with
holder, 09050-3031 &
faston
