Tektronix AFG31000 Series Service Manual

Removal and installation
72
AFG31000 Series Arbitrary Function Generator Service Manual
Exploded diagram replaceable parts - module rear chassis upper
Use the following table and figure to determine the replaceable parts and modules in your AFG
module rear chassis upper.
Index
number
Tektronix part
number
Instrument model Quantity Name and description
-01
441-2878-00
AFG31021
AFG31051
AFG31101
AFG31151
AFG31251
AFG31022
AFG31052
AFG31102
AFG31152
1
Chassis rear top side
441-2919-00
AFG31252
1
Chassis rear top side FIP
-02
119-7271-04
AFG31021
AFG31051
AFG31101
AFG31151
AFG31251
AFG31022
AFG31052
AFG31102
AFG31152
AFG31252
1
Power supply; ac-dc;
150 W max in;
87-264 V ac, 47-63 HZ,
100-127 V ac, 360-440
HZ in; +4.3V @ 2.3A,
+7.5V @ 3.2A, +18V @
2A, -18V @ 2A out;
safety controlled
-03
119-8853-00
AFG31022
AFG31052
AFG31102
AFG31152
AFG31252
1
Power supply; ac-dc;
internal; 85 - 265 V ac,
47-63 HZ, means input;
30-watt, single output 12
V dc, 2.5A; no case;
safety controlled
-04
441-2880-00
AFG31021
AFG31051
AFG31101
AFG31151
AFG31251
AFG31022
AFG31052
AFG31102
AFG31152
AFG31252
1
Cover, protection power
supply cover
