Tektronix AFG31000 Series Service Manual

Removal and installation
AFG31000 Series Arbitrary Function Generator Service Manual
73
Index
number
Tektronix part
number
Instrument model Quantity Name and description
-05
211-1272-00
AFG31021
AFG31051
AFG31101
AFG31151
AFG31251
AFG31022
AFG31052
AFG31102
AFG31152
AFG31252
12
Screw, machine;
6-32 X 0.250, PNH, STL,
ZNPL, T-15 Torx
-06
119-8177-00
AFG31021
AFG31051
AFG31101
AFG31151
AFG31251
AFG31022
AFG31052
AFG31102
AFG31152
AFG31252
1
Fan, tube axial (92 MM,
dc, assembly), safety
controlled
-07
348-2082-00
AFG31021
AFG31051
AFG31101
AFG31151
AFG31251
AFG31022
AFG31052
AFG31102
AFG31152
AFG31252
4
Grommet, fan mount,
noise damping
-08
174-7031-00
AFG31021
AFG31051
AFG31101
AFG31151
AFG31251
AFG31022
AFG31052
AFG31102
AFG31152
AFG31252
1
Cable, power auxiliary
supply to SG board
-09 337-4850-00 AFG31252 1 Absorber NFS40100
-10
253-0583-00
AFG31252
1
Conductive fabric tape
for shielding 87580-STD
-11
346-0299-00
AFG31021
AFG31051
AFG31101
AFG31151
AFG31251
AFG31022
AFG31052
AFG31102
AFG31152
AFG31252
1
Cable ties
