Command Groups
Table 2-41: Trigger Commands (cont.)
Command
Description
TRIGger:A:BUS:B <x>:SPI:DATa:SIZe This command specifies the length of the data s tring in bytes to be used for
SPI trigger
TRIGger:A:BUS:B <x >:USB:ADDRess:HIVALue This command specifies the high limit for the USB trigger address
TRIGger:A:BUS:B<x>:USB :ADDRess:VALue This command specifies the value for the USB trigger address
TRIGger:A:BUS:B <x>:USB:CONDition This command specifies the U SB trigger condition
TRIGger:A:BUS:B<x>:USB :DATa:HIVALue This command specifies the high limit for the USB trigger data
TRIGger:A:BUS:B <x>:USB:DATa:OFFSet This command specifies the data offset for the USB trigger data
TRIGger:A:BUS:B <x>:USB:DATa:SIZe This command specifies the number of data bytes for the USB trigger
TRIGger:A:BUS:B <x>:USB:DATa:TYPe This command specifies the data type for the USB trigger
TRIGger:A:BUS:B <x>:USB:DATa:VALue This command specifies the data value for the USB trigger
TRIGger:A:BUS:B<x>:USB :ENDPoint:VALue This command specifies the endpoint value for the USB trigger
TRIGger:A:BUS:B <x>:USB:ERRTYPE This command specifies the error type for the USB trigger
TRIGger:A:BUS:B<x>:USB :HANDSHAKEType This command speci fies the handshake type for the USB trigger
TRIGger:A:BUS:B <x >:USB:QUALifier This command specifies the qualifier for USB trigger
TRIGger:A:BUS:B <x >:USB:SOFFRAMENUM ber This command specifies the SOF number for the USB trigger
TRIGger:A:BUS:B<x>:USB :SPECIALType This command specifies the special packet type for the US B trigger
TRIGger:A:BUS:B<x>:USB :SPLit:ET:VALue When triggering on a high-speed USB split transaction, this command specifies
the split transaction endpoint type value to trigger on.
TRIGger:A:BUS:B<x>:USB :SPLit:HUB:VALue When triggering on a high-speed USB split transaction, this command specifies
the split transaction hub address value to trigger on.
TRIGger:A:BUS:B<x>:USB :SPLit:PORT:VALue When triggering on a high-speed USB split transaction, this command specifies
the split transaction port address value to trigger on.
TRIGger:A:BUS:B<x>:USB :SPLit:SC:VALue When triggering on a high-speed USB split transaction, this command specifies
whether to trigger on the start or complete phase of the split transaction, based
on the Start/Complete bit field value.
TRIGger:A:BUS:B<x>:USB :SPLit:SE:VALue When triggering on a high-speed USB split transaction, this command specifies
the split transaction start/end bit value to trigger on.
TRIGger:A:BUS:B <x>:USB:TOKENType This command specifies the token type for the USB trigger
TRIGger:A:BUS:S OUrce This command specifies the s ource for a bus trigger
TRIGger:A:EDG E? Returns the source, coupling and source for the A edge trigger
TRIGger:A:EDGE:COUPling This command specifies the type of coupling for the A edge trigger
TRIGger:A:EDGE:SLOpe This command specifies the slope for the A edge trigger: rising, falling or either.
TRIGger:A:EDGE:SOUrce This command specifies the source for the A edge trigger
TRIGger:A:HOLDoff? Returns the A trigger holdoff parameters
TRIGger:A:HOLDoff:TIMe This command specifies the A trigger holdoff time
TRIGger:A:LEVel:AUXin Sets the threshold voltage level for an Edge, Pulse Width, Runt or Rise/Fall
(aka Transition, aka Slew Rate) trigger to use when triggering on the A ux
Input connector signal.
MDO4000/B/C, MSO/DPO4000B and MDO3000 Series Oscilloscopes Programmer Manual 2-87
