Measurement Description
Global Measurement Settings
Set the reference levels. See Global Measurement Settings panel (Measurement
configuration menu) on page 1
12
Safe Operating Area Measurements panel (optional)
Measurement Description
SOA Pair
Select which channels to measure. For this measurement, there are four valid voltage/
current input pairs. These are Ch1/Ch2, Ch3/Ch4, Reference 1/Reference 2, and
Reference 3/Reference 4.
Axes
Select either a log or linear graticule. Use the max and min menu items and multipurpose
knob a to set the size of the graticule.
The x axis typically displays voltage and the y axis displays current.
Y Axis Max
Set the Y axis maximum value.
Y Axis Min
Set the Y axis minimum value.
X Axis Max
Set the X axis maximum value.
X Axis Min
Set the X axis minimum value.
Stop On Violation
Select whether or not to stop acquisitions on the detection of an error.
Mask Settings panel
Define a mask for the measurement. See SOA Mask definition controls and
fields on page 1
15
Mask Settings panel (optional)
Measurement Description
Define Mask
Selects setting limits or setting points to define a mask.
Maximum Voltage
Set the maximum voltage using a multipurpose knob or double-tap and set the value using
the displayed keypad.
Maximum Current
Set the maximum current using a multipurpose knob or double-tap and set the value using
the displayed keypad.
Maximum Power
Set the maximum power using a multipurpose knob or double-tap and set the value using
the displayed keypad.
Define Mask
Lists the points that define a mask. Set the X and Y values using the multipurpose knobs.
Insert Point
Inserts a new mask point.
Delete Point
Deletes the selected mask point.
Table continued…
