• Arbitrary function record length: 128K samples
•
AM and FM modulation
Table 4: 3 Series AFG option
Option name Description
3-AFG Adds a arbitrary function generator with 13 predefined waveforms and arbitrary waveform generation.
Enhanced instrument security
The enhanced instrument security option provides the highest level of instrument security
. This option enables password protecting and
disabling of all communication ports and firmware upgrades. This option configures the oscilloscope hardware to easily declassify the
oscilloscope. This option must be ordered at the same time you order an instrument. You cannot order this option as a field-installable
upgrade, as the option requires hardware reconfiguration.
Table 5: Enhanced instrument security pre-installed option
Install option name Description
3-SEC Enhanced instrument security to enable password protected control of turning on/off all instrument
ports and instrument firmware update functionality
.
Serial bus decode and trigger options
Serial bus and trigger options provide bus decode display and triggering for testing and analysis of industry standard serial buses.
Table 6: 3 Series serial bus options
Option name Description
3-SRAERO Adds aerospace serial triggering and analysis (MIL-STD-1553, ARINC429)
3-SRAUDIO
Adds audio serial triggering and analysis (I
2
S, LJ, RJ, TDM)
3-SRAUTO Adds automotive serial triggering and analysis (CAN, CAN FD, LIN, FlexRay)
3-SRCOMP Adds computer serial triggering and analysis (RS-232/422/485/UART)
3-SREMBD
Adds embedded serial triggering and analysis (I
2
C, SPI)
3-SRUSB2 Adds USB serial triggering and analysis (USB 2.0 LS, FS, HS)
Power Analysis option
The power analysis option enables analysis of many dif
ferent power measurements: power quality, switching loss, harmonics, modulation,
ripple, slew rate (di/dt, dv/dt), and safe operating area (SOA).
Table 7: 3 Series power option
Upgrade option name Description
3-PWR
Adds power measurement and analysis.
Factory options
3 Series Mixed Domain Oscilloscope Printable Help 26
