Field or control Description
Act On Trigger
Set the actions the instrument takes when a trigger event occurs.
For additional information on the Act On T
rigger panel see Act On Trigger configuration
menu on page 227.
MIL-STD-1553 serial bus trigger settings panel
Use the MIL-STD-1553 bus menu (optional) to set up and decode a MIL-STD-1553 aeronautic network serial data bus waveform.
Note: Requires option SRAERO.
Field or control Description
Source Select the MIL-STD-1553 bus on which you want to trigger
.
Trigger On Select the type of information on which to trigger.
Error Type Sets the error condition on which to trigger.
Available when Trigger On = Error.
Parity Sets to trigger on the selected parity bit logic state.
Available when Trigger On = Command, Status, or Data.
Data Sets the data pattern on which to trigger.
Available when Trigger On = Data.
Trigger When Sets to trigger when the specified RT/IMG signal time condition occurs.
Available when Trigger On = Time (RT/IMG).
Maximum Time Sets the maximum time for a valid RT/IMG signal.
Available when Trigger On = Time (RT/IMG).
Minimum Time Sets the minimum time for a valid RT/IMG signal.
Available when Trigger On = Time (RT/IMG).
Transmit/Receive Bit Sets the transmit or receive bit on which to trigger.
Available when Trigger On = Command.
Trigger When RT Address Sets to trigger when the specified RT address condition occurs.
Available when Trigger On = Command or Status.
Parity Sets to trigger when the specified parity condition occurs.
Available when Trigger On = Command or Status.
Table continued…
Menus and dialog boxes
3 Series Mixed Domain Oscilloscope Printable Help 209
