Field or control Description
Mark When Sets the mark when condition.
When set to Inside Range
or Outside Range, fields are displayed to set a high and low boundary
pattern for the specified search range.
Only available when Mark On = Identifier or Cycle Count.
Frame Type Sets the end of frame type for which to search.
Only available when Mark On = End of Frame.
Error Type Sets the error type for which to search.
Only available when Mark On = Error.
A, B knob controls Use the A knob to select (highlight) the digit(s) to change.
Use the B knob to change the value of the digit(s).
Or double-tap the field and use the virtual keypad to enter the data. See Binary, decimal, hex, and
octal virtual keypads on page 228.
Copy Trigger Settings to
Search
Sets the search criteria to match the current oscilloscope trigger settings. If the trigger settings are not
valid in Search, this control is either not available or grayed out.
Copy Search Settings to
Trigger
Sets the current oscilloscope trigger settings to match the search criteria.
I2C serial bus search configuration menu
Use the I2C Search configuration menu to define conditions to search for and mark on an I2C bus waveform.
Note: Requires option SREMBD.
Field or control Description
Display Enables or disables displaying search marks on this search.
Source
Select the I
2
C bus that you want to search.
Mark On Select the type of information for which to search.
Direction Sets the transfer direction for which to search.
Only available when Mark On = Address or Address & Data.
Table continued…
Menus and dialog boxes
3 Series Mixed Domain Oscilloscope Printable Help 143
