Input Description
RF input maximum input voltage
Average Continuous Power: +20 dBm (0.1 W)
DC maximum before damage: ±40 VDC
Max no damage +33 dBm (2 W) CW
Peak Pulse Power: +45 dBm (32 W)
Peak Pulse Power defined as <10
μs pulse width, <1% duty cycle, and reference
level of ≥ +10 dBm
Table 13: Maximum input with a P6316 Digital Probe
Input Description
Threshold Accuracy ±(100 mV + 3% of threshold setting after calibration)
Threshold Range +25 V to –15 V
Maximum nondestructive input signal to probe +30 V to -20 V
Minimum signal swing 500 mV
peak-to-peak
Input resistance 101 kΩ
Input capacitance 8.0 pF typical
Pollution Degree 2, indoor use only
Humidity 5% to 95% relative humidity
Powering the oscilloscope
Use this procedure to connect the oscilloscope to line power and power on and of
f the oscilloscope. Always connect the oscilloscope to AC
power using the power cord that shipped with the instrument.
Before you begin
Prerequisite: Use the AC power cord that shipped with your oscilloscope.
Procedure
1. Connect the supplied power cord to the oscilloscope power connector.
Install your instrument
3 Series Mixed Domain Oscilloscope Printable Help 34
