Field or control Description
Data Offset Sets the data offset (Don't Care or the number of bytes). T
ap the input box and use the A knob to
change the value.
Available when Trigger On = Data or Identifier & Data.
Data Sets the data pattern on which to trigger. The number of bits shown depends on the Data Bytes
setting. Use in conjunction with the Trigger When field to specify the exact trigger condition.
Tap the Binary or Hex field and use the A and B knobs to select and change the values. Or double-tap
on the field and use the virtual keypad to enter values. See Binary, decimal, hex, and octal virtual
keypads on page 228.
Available when Trigger On = Data or Identifier & Data and Trigger When Data is not set to Inside
Range or Outside Range.
Data High Sets the data high pattern which, if exceeded, will cause a trigger.
Tap the Binary or Hex field and use the A and B knobs to select and change the values. Or double-tap
on the field and use the virtual keypad to enter values.
Available when Trigger On = Data or Identifier & Data and Trigger When Data is set to Inside
Range or Outside Range.
Data Low Sets the data low pattern which, if exceeded, will cause a trigger.
Tap the Binary or Hex field and use the A and B knobs to select and change the values. Or double-tap
on the field and use the virtual keypad to enter values.
Available when Trigger On = Data or Identifier & Data and Trigger When Data is set to Inside
Range or Outside Range.
A, B knob controls Use the A knob to select (highlight) the digit(s) to change.
Use the B knob to change the value of the digit(s).
Mode & Holdoff
Trigger Mode determines how the instrument behaves in the absence or presence of a trigger event.
Holdoff sets the amount of time the oscilloscope waits after a trigger event before detecting and
triggering on the next trigger event.
For additional information on Trigger Mode, Holdoff, forcing a trigger, and the Trigger Frequency
Counter see Mode and Holdoff panel on page 226.
Act On Trigger
Set the actions the instrument takes when a trigger event occurs.
For additional information on the Act On Trigger panel see Act On Trigger configuration
menu on page 227.
I2C serial bus trigger settings panel
Use the I2C bus menu (optional) to set up and display an I
2
C (Inter-Integrated Circuit) serial bus waveform.
Note: Requires option SREMBD.
Menus and dialog boxes
3 Series Mixed Domain Oscilloscope Printable Help 206
