MIL-STD-1553 Search configuration menu
Use the MIL-STD-1553 Search configuration menu to define conditions to search for and mark on an MIL-STD-1553 bus waveform.
Note: Requires option SRAERO.
Field or control Description
Display Enables or disables displaying search marks on this search.
Source Select the MIL-STD-1553 bus that you want to search.
Mark On Select the type of information for which to search.
Transmit/Receive Bit Sets the transmit or receive bit state for which to search.
Only available when Mark On = Command.
Mark When Sets when to place a mark.
When set to Inside Range
or Outside Range, fields are displayed to set a high and low boundary
pattern for the specified search range.
Only available when Mark On = Time (RT/IMG).
Maximum Time and Minimum
Time
Sets the high and low boundary for the specified search range.
Only available when Mark On = Time (RT/IMG).
Mark When RT Address Sets the RT address condition for which to search.
When set to Inside Range or Outside Range, fields are displayed to set a low and high address for
the specified search range.
Only available when Mark On = Command or Status.
Parity Sets the parity state for which to search.
Only available when Mark On = Command or Status.
Address Sets the address value for which to search.
Tap the Binary, Hex, or Decimal field and use the A and B knobs to select and change the values. Or
double-tap on the field and use the virtual keypad to enter values.
Only available when Mark When RT Address ≠ Inside Range or Outside Range.
Table continued…
Menus and dialog boxes
3 Series Mixed Domain Oscilloscope Printable Help 146
