Tektronix MDO32 User Manual

Field or control Description
Source Select the LIN bus on which to trigger
.
Trigger On Select the type of information on which to trigger.
Identifier Sets the identifier pattern on which to trigger.
Tap the Binary, Hex, or Dec field and use the A and B knobs to select and change the values. Or
double-tap on the field and use the virtual keypad to enter values.
Available when Trigger On = Identifier or Identifier & Data.
Trigger When Data Sets the trigger when condition.
When set to Inside Range or Outside Range, fields are displayed to set a high and low boundary
pattern for the specified trigger type.
Available when Trigger On = Data or Identifier & Data.
Data Bytes Sets the number of data bytes on which to trigger (one to eight bytes). Use the A knob to change the
value.
Available when Trigger On = Data or Identifier & Data.
Data Sets the data pattern on which to trigger. The number of bits shown depends on the Data Bytes
setting.
Tap the Binary or Hex field and use the A and B knobs to select and change the values. Or double-tap
on the field and use the virtual keypad to enter values. See Binary, decimal, hex, and octal virtual
keypads on page 228.
Available when Trigger On = Data or Identifier & Data and Trigger When Data is not set to Inside
Range or Outside Range.
Data High Sets the data pattern high limit which, if exceeded, will cause a trigger.
Available when Trigger On = Data or Identifier & Data and Trigger When Dataa is set to Inside
Range or Outside Range.
Data Low Sets the data pattern low limit which, if exceeded, will cause a trigger.
Available when Trigger On = Data or Identifier & Data and Trigger When Dataa is set to Inside
Range or Outside Range.
Error Type Sets the LIN error type on which to trigger.
Available when Trigger On = Error.
A, B knob controls Use the A knob to select (highlight) the digit(s) to change.
Use the B knob to change the value of the digit(s). Or double-tap on the field and use the virtual
keypad to enter values.
Mode & Holdoff
Trigger Mode determines how the instrument behaves in the absence or presence of a trigger event.
Holdoff sets the amount of time the oscilloscope waits after a trigger event before detecting and
triggering on the next trigger event.
For additional information on Trigger Mode, Holdoff, forcing a trigger, and the Trigger Frequency
Counter see Mode and Holdoff panel on page 226.
Table continued…
Menus and dialog boxes
3 Series Mixed Domain Oscilloscope Printable Help 208
