Field or control Description
ESI Bit Sets the ESI bit state for which to search.
Only available when Mark On = FD ESI Bits.
Identifier Format Sets the identifier for Standard (11-bit) or Extended (29-bit for CAN 2.0B) length.
Only available when Mark On = Identifier or ID & Data.
Identifier Sets the identifier pattern for which to search. The number of bits shown depends on the Identifier
Format setting.
T
ap the Binary or Hex field and use the A and B knobs to select and change the values. Or double-tap
on the field and use the virtual keypad to enter values.
Only available when Mark On = Identifier or ID & Data.
Search When Data Sets the data to search for.
Only available when Mark On = Identifier or ID & Data.
Data Bytes Sets the number of data bytes for which to search (one to eight bytes). Use the A knob to change the
value.
Only available when Mark On = Data or Identifier & Data .
Data Offset Sets the data offset in bytes to delay the trigger. Use the A knob to change the value.
Only available when Mark On = Data or Identifier & Data .
Data Sets the data pattern for which to search. The number of bits shown depends on the Data Bytes
setting.
Tap the Binary or Hex field and use the A and B knobs to select and change the values. Or double-tap
on the field and use the virtual keypad to enter values.
Only available when Mark On = Data or Identifier & Data .
A, B knob controls Use the A knob to select (highlight) the digit to change.
Use the B knob to change the value of the digit.
Or double-tap the field and use the virtual keypad to enter the data. See Binary, decimal, hex, and
octal virtual keypads on page 228.
Table continued…
Menus and dialog boxes
3 Series Mixed Domain Oscilloscope Printable Help 140
