Field or control Description
Source Select the CAN bus on which you want to trigger
.
Trigger On Select the type of information on which to trigger.
Frame Type Sets the frame type on which to trigger.
Available when Trigger On = Type of Frame.
FD BRS Bit Sets the FD BRS or EIS bit to X, 0, or 1.
Available when Source is a CAN FD bus and Trigger On = FD BRS Bit.
FD ESI Bit Sets the FD BRS or EIS bit to X, 0, or 1.
Available when Source is a CAN FD bus and Trigger On = FD ESI Bits.
Trigger When Data Select the Trigger When Data condition from the drop down list.
Available when Trigger On = Data or Identifier & Data.
Identifier Format Sets the identifier for standard (11-bit) or extended (29-bit for CAN 2.0B) length.
Available when Trigger On = Identifier or Identifier & Data.
Data Bytes Sets the number of data bytes on which to trigger (one to eight bytes). Use the A knob to change the
value.
Available when Trigger On = Data or Identifier & Data.
Data Offset Sets the data offset in bytes to delay the trigger.
Available when Trigger On = Data or Identifier & Data.
Identifier Sets the identifier pattern on which to trigger. The number of bits shown depends on the Identifier
Format setting.
Tap the Binary or Hex field and use the A and B knobs to select and change the values. Or double-tap
on the field and use the virtual keypad to enter values.
Available when Trigger On = Identifier or Identifier & Data.
Data Sets the data pattern on which to trigger. The number of bits shown depends on the Data Bytes
setting.
Tap the Binary or Hex field and use the A and B knobs to select and change the values. Or double-tap
on the field and use the virtual keypad to enter values. See Binary, decimal, hex, and octal virtual
keypads on page 228.
Available when Trigger On = Data or Identifier & Data.
A, B knob controls Use the A knob to select (highlight) the digit(s) to change.
Use the B knob to change the value of the digit(s).
Table continued…
Menus and dialog boxes
3 Series Mixed Domain Oscilloscope Printable Help 203
