Command Groups
Table 2-41: Trigger Commands (cont.)
Command
Description
TRIGger:A:BUS:B<x>:MIL1553B :CO MMAND:
ADDRess:HIVALue
When the MIL-STD-1553 bus trigger condition is set to COMMAND, and the
qualifier is set to
INrange or OUTrange, this command specifies the upper
limit of the range for the remote terminal address field.
TRIGger:A:BUS:B<x>:MIL1553B :CO MMAND:
ADDRess:QUALifier
When the MIL-STD-1553 bus trigger condition is set to COMMAND,this
command specifies the qualifier to be used with the remote terminal address
field.
TRIGger:A:BUS:B<x>:MIL1553B :CO MMAND:
ADDRess:VALue
When the MIL-STD-1553 bus trigger condition is set to COMMAND,and
the qualifier is set to
LESSthan, MOREthan, EQual, UNEQual,
LESSEQual
or MOREEQual, this command specifies the value of the 5–bit
remote terminal address to be used in the trigger.
TRIGger:A:BUS:B<x>:MIL1553B :CO MMAND:
COUNt
When the MIL-STD-1553 bus trigger condition is set to COMMAND,this
command specifies the bit pattern for the 5–bit Word C ount/Mode Code
sub-address field that is to be used in the trigger.
TRIGger:A:BUS:B<x>:MIL1553B :CO MMAND:
PARity
When the MIL-STD-1553 bus trigger condition is set to COMMAND,this
command specifies the Command word parity that is to be used in the trigger.
TRIGger:A:BUS:B<x>:MIL1553B :CO MMAND:
SUBADdress
When the MIL-STD-1553 bus trigger condition is set to COMMAND,this
command specifies the 5 bit sub-address that is to be used in the trigger.
TRIGger:A:BUS:B<x>:MIL1553B :CO MMAND:
TRBit
When the MIL-STD-1553 bus trigger condition is set to COMMAND,this
command specifies that the transmit/receive bit (bit 9) is to be used in the
trigger.
TRIGger:A:BUS:B<x>:MIL1553B :CONDition This command specifies a word type or condition within a MIL-STD-1553 bus
word to trigger on.
TRIGger:A:BUS:B<x>:MIL1553B :DATa:PARity When the MIL-STD-1553 bus trigger condition is set to DATa, this c ommand
specifies the data parity bit to be used in the trigger.
TRIGger:A:BUS:B<x>:MIL1553B :DATa:VALue When the MIL-STD-1553 bus trigger condition is set to DATa, this command
specifies the data binary pattern to be used in the trigger.
TRIGger:A:BUS:B<x>:MIL1553B :ERRTYPE When the MIL-STD-1553 bus trigger condition is set to ERRor, this command
specifies the signaling error type to be used in the trigger: Parity, Sync,
Manchester or Data.
TRIGger:A:BUS:B<x>:MIL1553B :STATus:
ADDRess:HIVALue
When the MIL-STD-1553 bus trigger condition is set to STATus, and the
qualifier is set to
INrange or OUTrange, this command specifies the upper
limit for the 5 bit remote terminal address field of the Status word.
TRIGger:A:BUS:B<x>:MIL1553B :STATus:
ADDRess:QUALifier
When the MIL-STD-1553 bus trigger condition is set to ST ATus, this command
specifies the qualifier to be used with the address field.
TRIGger:A:BUS:B<x>:MIL1553B :STATus:
ADDRess:VALue
When the MIL-S TD-1553 bus trigger condition is set to STATus, and
the qualifier is set to
LESSthan, MOREthan, EQual, UNEQual,
LESSEQual
or MOREEQual, this command specifies the value of the 5–bit
remote terminal address to be used in the trigger.
TRIGger:A:BUS:B<x>:MIL1553B :STATus:BIT:BCR When the MIL-STD-1553 bus trigger condition is set to STATus, this command
specifies the status w ord broadcast command received (BCR) bit value (bit
15) to be used in the trigger.
TRIGger:A:BUS:B<x>:MIL1553B :STATus:BIT:
BUSY
When the MIL-STD-1553 bus trigger condition is set to ST ATus, this command
specifies the status word busy bit value (bit 16) to be used in the trigger.
MDO4000/B/C, MSO/DPO4000B and MDO3000 Series Oscilloscopes Programmer Manual 2-85
