Command Groups
Table 2-33: Measurement Commands (cont.)
Command
Description
MEASUrement:IMMed:DELay? Returns information about the immediate delay measurement
MEASUrement:IMMed:DELay:
DIRection
This command specifies the search direction to use for immediate delay measurements
MEASUrement:IMMed:DELay:
EDGE<x>
This command specifies the slope of the edge used for immediate delay “from” and “to”
waveform measurements
MEASUrement:IMMed:SO Urce<x> This command specifies the “from” source for all single channel immediate measurements
This command specifies the source to measure “to” for two-channel measurements
MEASUrement:IMMed:TYPe This command specifies the type of the immediate measurement
MEASUrement:IMMed:UN Its? Returns the units of the immediate measurement
MEASUrement:IMMed:VALue? Returns the value of the immediate measurement
MEASUrement:INDICa tors?
Returns all measurement indicator parameters
MEASUrement:INDICa tors:
HORZ<x>?
Returns the position of the specified horizontal measurement indicator
MEASUrement:INDICa tors:
NUMHORZ?
Returns the number of horizontal measurement indicators currently being displayed
MEASUrement:INDICa tors:
NUMVERT?
Returns the number of vertical measurement indicators currently being displayed
MEASUrement:INDIC ators:STATE This command specifies the state of visible m easurement indicators
MEASUrement:INDICa tors:
VERT<x>?
Returns the value of the specified vertical measurement indicator
MEASUrement:MEAS<x>?
Returns all measurement parameters
MEASUrement:MEAS<x>:COUNt? Returns the number of values accumulated since the last statistical reset
MEASUrement:MEAS<x>:DELay? Returns the delay measurement parameters for the specified measurement
MEASUrement:MEAS<x>:DELay:
DIRection
This command specifies the search direction to use for delay measurements
MEASUrement:MEAS<x>:DELay:
EDGE<x>
This command specifies the slope of the edge to use for delay “from” and “to” waveform
measurements
MEASUrement:MEAS<x>:
MAXimum?
Returns the maximum value found since the last statistical reset
MEASUrement:MEAS<x>:MEAN?
Returns the mean value accum u lated since the last statistical res e t
MEASUrement:MEAS<x>:
MINImum?
Returns the minimum value found since the last statistical reset
MEASUrement:MEAS<x>:
SOUrce<x>
This command specifies the “from” source for all single channel immediate measurements
This command specifies the source to measure “to” for two-channel measurements
MEASUrement:MEAS<x>:STATE This command specifies whether the specified measurement slot is computed and displayed
MEASUrement:MEAS<x>:STDdev? Returns the standard deviation of values accumulated since the last statistical reset
MEASUrement:MEAS<x>:TYPe This command specifies the measurement<x> type
MEASUrement:MEAS<x>:UNIts?
Returns measurement<x> units
MEASUrement:MEAS<x>:VALue? Returns the value of measurement<x>
MDO4000/B/C, MSO/DPO4000B and MDO3000 Series Oscilloscopes Programmer Manual 2-37
