Tektronix MDO4000B Series User Manual

Command Groups
Table 2-36: Power Commands (cont.)
Command Description
POWer:HARMonics:RESults:
HAR<1-400>:TEST:IEC:
CLASSALIMit?
Returns PASS, FAIL or NA. Specifies if the IEC Class A higher harmonic limit (and
conditions) are met
POWer:HARMonics:RESults:
HAR<1-400>:TEST:IEC:NORMAL?
Returns PASS, FAIL or NA. Specifies if the Normal IEC harmonic limits are met
POWer:HARMonics:RESults:
HAR<1-400>:TEST:IEC:POHCLIMit?
Returns PASS, FAIL or NA. Specifies if the higher harmonic limit (and conditions) for the 21st
and higher order odd harmonics are met
POWer:HARMonics:RESults:
HAR<1-400>:TEST:MIL:NORMAL?
Returns the test result for the specified harmonic for the MIL-STD-1399 Section 300A testing
standard
POWer:HARMonics:RESults:IEC:
FUNDamental?
Returns the IEC fundamental frequency
POWer:HARMonics:RESults:IEC:
HARM3ALTernate?
Returns the IEC harmonics test result for the 3rd harmonic: PASS, FAIL or NA
POWer:HARMonics:RESults:IEC:
HARM5ALTernate?
Returns the IEC harmonics test result for the 5th harmonic: PASS, FAIL or NA
POWer:HARMonics:RESults:IEC:
POHC?
Returns the IEC POHC measurement
POWer:HARMonics:RESults:IEC:
POHL?
Returns the IEC POHL measurement
POWer:HARMonics:RESults:IEC:
POWer?
Returns the IEC input power measurement
POWer:HARMonics:RESults:IEC:
POWERFactor?
Returns the IEC power factor measurement
POWer:HARMonics:RESults:
PASSFail?
Returns the overall harmonics test result: PASS, FAIL or NA
POWer:HARMonics:RESults:RMS? Returns the root mean square value of the source waveform
POWer:HARMonics:RESults:SAVe Saves the harmonic results to the specified file in CSV format
POWer:HARMonics:RESults:THDF? Returns the Total Harmonic Distortion ( THD) in percentage, measured as a ratio to the RMS
value of the fundamental component of the s ource waveform
POWer:HARMonics:RESults:THDR? Returns the Total Harmonic Distortion ( TH D) in percentage, measured as a ratio to the
RMS value of the source waveform
POWer:HARMonics:SOURce This command specifies the source waveform for harmonics tests
POWer:HARMonics:STANDard This command specifies the standard for harmonics tests
POWer:INDICators This command specifies the state of the measurement indicators for the power application
POWer:MODulation:SOUrce This command specifies the source waveform for modulation tests
POWer:MODulation:TYPe This command specifies the m odulation type
POWer:QUALity:APPpwr?
Returns the apparent power measurement
POWer:QUALity:DISplay:APPpwr This command specifies the display state for the apparent power readout
POWer:QUALity:DISplay:
FREQuency
This command specifies the display state for the frequency readout
MDO4000/B/C, MSO/DPO4000B and MDO3000 Series Oscilloscopes Programmer Manual 2-43
